HORIZON – Infinitely elegant
HORIZON Minimal Frames
HORIZON is inspired by the clearly defined line of the horizon. The minimalistic frame system for sliding windows allows for maximum transparency. The interior and exterior seem to flow into one another. For sophisticated architecture with an impact.
Free view
Unlimited view requires an invisible frame. For glass from floor to ceiling and from wall to wall, HORIZON Minimal Frames can therefore be fully integrated into the architecture.
Interested?
Perfection as standard - HORIZON Sol
SOL is the minimal frame system with double glazing. It combines all of the major HORIZON features.
Perfection as standard - HORIZON Sol
SOL is the minimal frame system with double glazing. It combines all of the major HORIZON features.
Excellence in every dimension - HORIZON Luna
LUNA is the advanced minimal frame system with triple glazing. In addition to optimal insulation, it also allows for a door size of up to 21 square meters.
Excellence in every dimension - HORIZON Luna
LUNA is the advanced minimal frame system with triple glazing. In addition to optimal insulation, it also allows for a door size of up to 21 square meters.
Thought-out details
And other advantages
HORIZON Minimal Frames convince when it comes to saving energy, resistance to water and wind, security, accessibility and comfort.
Developed with expertise
Developed from more than 80 years of experience, GUTMANN offers you an architectural highlight. The minimalistic system meets the highest demands of design, comfort and technology.
Flexible and customizable
Numerous opening types can be realized with HORIZON - for example, one, two and three rail systems as well as profile-free corner solutions for a 360-degree view.
Safe and comfortable
The concealed electronic drives and locks increase ease of use and security. The unique multi-point locking system offers excellent burglary protection in accordance with European standards.
Smooth and quiet
Stainless steel rollers and rails enable smooth gliding and particularly easy movement, even with large door dimensions.
High quality and durable
The precision-processed aluminium profiles have been optimized for particularly fast water drainage.
Dimensions and Possibilities
HORIZON Sol and HORIZON Luna in comparison
SOL | LUNA | ||
---|---|---|---|
Facing width | 24 | 30 mm | 24 | 30 mm | |
Installation flush to the floor | yes | yes | |
Installation flush to the ceiling | yes | yes | |
Max. leaf height | 4,5 m | 6,5 m | |
Max. leaf width | 3 m | 3 m | |
Max. leaf weight | 500 kg | 1000 kg | |
Max. sliding leaf area | 12 qm | 16 qm | |
Max. fix leaf dimension | 18 qm | 21 qm | |
Motorization | yes | yes | |
“invisible” railing | yes | yes | |
Glass thickness | 30 - 36 mm | 49 - 54 mm |
SOL | LUNA | ||
---|---|---|---|
Facing width | 24|30mm | 24|30mm | |
Installation flush to the floor | yes | yes | |
Installation flush to the ceiling | yes | yes | |
Max.leaf height | 4,5m | 6,5m | |
Max.leaf width | 3m | 3m | |
Max.leaf weight | 500kg | 1000kg | |
Max.sliding leaf area | 12qm | 16qm | |
Max.fix leaf dimension | 18qm | 21qm | |
Motorization | yes | yes | |
“Invisible” railing | yes | yes | |
Glass thickness | 30-36mm | 49-54mm |
A brochure with all of the technical specifications can be downloaded here as a PDF.
New Horizons
Current references and future projects
Project Nizza
Location Nizza, France Completion Date expected summer 2020 System Sol Invisible Project Size 26qm Architect – Fabricator Fensterbau Jähnke GmbH
Villa „Yarze“, Libanon
Location Yarze, Libanon Completion Date 2018 System GUTMANN HORIZON SOL Client ARCADIA s.a.r.l.
Loncke
Title Loncke Completion 2016 System GUTMANN HORIZON SOL
Claeys
Title Claeys Completion 2017 System GUTMANN HORIZON SOL Architect Arnoud Hulpia
Project Nizza
Location Nizza, France Completion Date expected summer 2020 System Sol Invisible Project Size 26qm Architect – Fabricator Fensterbau Jähnke GmbH
Villa Riad, Saudi-Arabia
Location Riad, Saudi-Arabia Completion Date 2018 System GUTMANN HORIZON LUNA
Claeys
Title Claeys Completion 2017 System GUTMANN HORIZON SOL Architect Arnoud Hulpia
Villa Leie
Title Villa Leie Completion 2019 System GUTMANN HORIZON LUNA Architect Marc Beernaerts
BVH Esslingen
Standort: Esslingen, Deutschland
Fertigstellung: voraussichtlich Herbst 2020
System: Luna Invisible
Flächenmenge: 67 qm
Architekt: M.Wuppermann
Verarbeiter: Gräfle Fensterbau e.K.
Project Nizza
Location Nizza, France Completion Date expected summer 2020 System Sol Invisible Project Size 26qm Architect – Fabricator Fensterbau Jähnke GmbH
Antwerpen
Title Antwerpen Completion 2019 System GUTMANN HORIZON LUNA
Loncke
Title Loncke Completion 2016 System GUTMANN HORIZON SOL
